Model:CNME0101VET-3
Features:
7" high resolution color LCD display with adjustable brightness.
Lightweight and portable, easy for veterinarians to carry out.
Built-in rechargeable lithium battery for long term continuous operation.
3 leads and 5 leads ECG cable are selectable.
Variety of NIBP Cuffs for different size animals.
Expanded heart rate values and Veterinary specific SpO2 sensors to accommodate a variety of species.
Widely used in pet hospitals and animal clinics etc.
Specifications:
| SpO2 | |
| Aturation range | 1% to 100% |
| Accuracy | 70-100%(±2%),<70% undefined |
| Resolution | 1% |
| Display sweep speed | 10.00 mm/sec |
| Pulse Rate | |
| Aturation range | 25bpm to 350bpm |
| Accuracy | ±2bpm/±2% take maximum |
| Resolution | 1 bpm |
| ECG | |
| Aturation range | 25bpm to 350bpm |
| Accuracy | ±2bpm/±2% take maximum |
| Resolution | 1 bpm |
| Leads | I,II,III,V,aVR,aVL or aVL |
| Display gain | X1/4,X1/2,X1,X2,X4 |
| Display sweep speed | 6.25,12.5,25,50mm/sec |
| NIBP | |
| Method | Oscillometric |
| Aturation Range | 0-300mmHg |
| Accuracy | Based on ANSI/AAMI SP10:1992 and 2002 Standards |
| Measurement Time | 30-50s typical,180s maximum |
| AUTO Interval Times | 2,3,5,10,30 min, or 1,2h |
| RESP | |
| Aturation range | 0-130rpm |
| Accuracy | ±1pm |
| Resolution | 1rpm |
| TEMP | |
| Aturation range | 0-50ºC |
| Accuracy | ±0.2ºC |
| Resolution | 0.1ºC |
